SteamSpa 9KW - Steam Generator Specifications

SteamSpa PHONE: 800-856-0172 FAX: 866-560-5662 http://steamspa.com info@steamspa.com
Page 9
INSTALLATION & USER GUIDE
STEAM GENERATOR SPECIFICATIONS
4.5kW
6kW/7.5kW/9kW
Safety valve
St eam outl et
Water i nl et
Water
drainage
206mm
188mm
151mm
32mm
43mm
142mm
266mm
302mm
395mm
Fuse for wire power supply
Power wire hole
C on tr o lle r w i r e
and light wi re hol e
304mm
400mm
16 0m m
10 0m m
30 mm
30mm
18 0mm
26 0m m
37 0mm
Steam outlet
S a f e t y
valve
Water inlet
Water drainage
Fuse for w ire pow er s upply
Power wire hole
C o n tro ller wire
an d lig h t wir e
hole
Fuse for wire
power supply
Fuse for wire
power supply
62mm
72mm
