6. Installation And Cautions
6.1. Installation cautions
DO NOT use locking pliers to over tight the DRAIN PIPE connection.
Before installation, MUST read all the install Cautions in this manual, on page 5.
Selecting the proper steam generator
In order to achieve comfort and relaxation, as well as energy efficiency, the selection of the correct
steam generator model and size are as critical as design of the steam room itself. The power supply
and circuit protector should be carefully checked to match the parameters of the generator. Please
referring to the table 2 & its notice and select the suitable model for your specification.
6.2. Installation of steam generator body
6.2.1. Cautions
Switch off all power supply before installation, and check whether you have the correct model for
your steam room according to table 2 & its notice.
Do not install the generator outdoors, in wet/moist place, freezing, or corrosive place. Do not
install the generator near to inflammables such as oil paint, diluents and fuel. Be alert to the
steam pipeline and safety valve since the high temperature of steam is dangerous to customers.
Generator must be level installed.
The generator should be installed in a dry and well-ventilated place. It can be installed either on
the wall or on the ground, but must be well fixed. Install the generator to steam room as close as
possible, such as in the closet, under the washing basin or in the basement. (Refer to figure 5).
6.2.2. Installation
i. Install the generator on the wall: drill two small holes with diameter of 8mm on the wall, insert
the expansion screws and then hang the generator on those screws.
ii. Install the generator on the ground or deck: install a frame on the site and then screw the
generator into the frame.
iii. Central function box should be installed near to the steam generator as near as possible, as the
length of the cable (connecting the steam generator and the central function box) is 50cm.
Please don’t use other extended cable, only the cable we provided is allowed.
iv. For better service and maintenance, please install the generator with the nameplate face to
front and leave more than 250mm space around the generator.
