SV1 User Manual
Product Name: GNSS RECEIVER
Brand Name: STEC, ZENITH
Model No.: SV1
guangzhou star information technology co.,ltd
hereby declares that this [Name: GNSS RECEIVER, Model: SV1] is in compliance with the essential
requirements and other relevant provisions of Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the internet address:
www.think2stec.com
The product shall only be connected to a USB interface of version USB2.0 and that the connection to a
power USB is allowed.
Adapter shall be installed near the equipment and shall be easily accessible.
Only can use adapter as below:
Power Adapter MODEL:DSA-45PDH
Input: AC100-240V~ 50/60Hz 1.5A
Output: DC5V3A/9V3A/12V/3A/15V3A/20V2.25A
DEE VAN ENTERPRISE CO.,LTD
The plug considered as disconnect device of adapter.
This product is intended for sale and application in a business environment.
RED Article 10 2
-This product can be used across EU member states
RED Article 10 10
-The product is class 1 product, No restrictions
The RF distance between body and product is 20cm.
Technical Characteristics of EUT
2G
Frequency Range:
GPRS900: Tx: 880-915MHz, Rx: 925-960MHz
GPRS1800: Tx: 1710-1785MHz, Rx: 1805-1880MHz
RF Output Power:
GPRS900: 34.19dBm, GPRS1800: 29.55dBm
EDGE900: 27.02dBm, EDGE1800: 25.99dBm
3G
Frequency Range:
WCDMA Band 1: Tx: 1920-1980MHz, Rx: 2110-2170MHz
WCDMA Band 8: Tx: 880-915MHz, Rx: 925-960MHz
RF Output Power:
WCDMA Band 1: 23.03dBm, WCDMA Band 8: 23.16dBm
4G
Frequency Range:
FDD-LTE Band 1: Tx: 1920-1980MHz, Rx: 2110-2170MHz
FDD-LTE Band 3: Tx: 1710-1785MHz, Rx: 1805-1880MHz
FDD-LTE Band 7: Tx: 2500-2570MHz, Rx: 2620-2690MHz
FDD-LTE Band 8: Tx: 880-915MHz, Rx: 925-960MHz
FDD-LTE Band 20: Tx: 832-862MHz, Rx: 791-821MHz
TDD-LTE Band 38: Tx: 2570-2620MHz, Rx: 2570-2620MHz
TDD-LTE Band 40: Tx: 2300-2400MHz, Rx: 2300-2400MHz
Max.RF Output Power:
FDD-LTE Band 1: 23.34dBm, FDD-LTE Band 3: 23.93dBm,
FDD-LTE Band 7: 23.01dBm, FDD-LTE Band 8: 23.59dBm,
