SteFly Canopy Flasher Manual Version 1.2 12
8 Technical Data
Size
Unit
Value
Number of LEDs
10
Wavelength of LED light
nm
predominant 490 570 (green)
Luminous flux
lm
3600
Mass canopy flasher
g
53
Mass control box
g
128
Mass on-off switch
g
10
Mass connection cables
included in the scope of
delivery
g
57
Dimensions canopy flasher
mm (length x width x height)
95 x 33 x 30
Dimensions control box
mm (length x width x height)
78 x 84 x 25
Dimensions on-off switch
mm (width x height)
15 x 31
Input Voltage
V DC
9 - 15
Amperage total for canopy
flasher and control box (w/o
charging mobile devices)
mA (@ 13,5 V, flashing
frequency “low”)
110
Amperage total for canopy
flasher and control box (w/o
charging mobile devices)
mA (@ 13,5 V, flashing
frequency medium”)
150
Amperage additional when
transferring data via Bluetooth
mA
20
Internal fuse on-off switch
A
4
USB-A charging port output
V / A
5 / 2
Operating temperature
°C
-30 to +60
Operating rel. humidity
%
0 - 95
Material control box housing
Black anodized aluminium
Material canopy flasher
housing
SLS printed plastic, painted
matt black; heat sink black
anodized aluminium
