Steg SDSP 6 - 8 Stand Installation Reference; Channel Stand Alone Treble Mode

PRODUCT BRIEF INTRODUCTION
[ 15 ]
PRODUCT BRIEF INTRODUCTION
[ 16 ]
12. X-OVER AND EQ CHARTS.
13. EQ SETTING.
8.STAND INSTALLATION REFERENCE
8.1 5 CHANNEL STAND ALONE TREBLE MODE
1.Red lines and slopes will change accordingly when
2 .EQ all frequency points can be move left or right.For 20Hz-20KHz can be any Regulation.
Q volue=1-12.
HP/LP of crossover and EQ are modified.
SubwooferSubwoofer
GroundGround
9. HP/SLOPE.
1.6dB/oct 12dB/oct 18dB/oct 24dB/oct 30dB/oct 36dB/oct.
42dB/oct 48dB/oct are available.
10. Filter Model.
To choose different Filter type Linkwitz Bessel Butterworth.
11. WRITE.
To save setting to DSP(POS1-POS8).
12. READ.
To read setting from DSP(POS1-POS8).
1
To delete setting from DSP(POS1-POS8).
