STEPCRAFT 210 - Machine Table; 5 Machine Operation; Operator; Work Piece

12
Accessory
Description
Tool length sensor
Sensor to measure the bottom edge of the end mill in a
spindle
Circular table and tailstock
4
th
axis CNC milling to process cylindrical work pieces
Exhaust adapter
Collector for dust and chips
Heating bed*
Heated machine table for 3D printing, necessary for
ABS plastic
Vacuum table*
Machine table to fix thin materials like foils, plastic
sheets
Clamping accessories
Variety of clamping accessories like adapters, steel
vices, rubber work piece holder, aluminum T-slot table
*Third party supplier
4.5 MACHINE TABLE
The machine table consists of a High Pressure Laminate (HPL) with a thickness of 8.0 mm / 0.31 inch.
The machine table can be easily replaced. It is possible to pull out the table to the front by removing the
attachment bracket with the two relevant screws (see item 3.1, position 2).
Dimensions of the original machine table:
Typ of machine
Length
Width
Thickness
STEPCRAFT 210
290 mm /
11.4 inch
222 mm /
8.3 inch
8 mm /
0.31 inch
STEPCRAFT 300
380 mm /
14.96 inch
234 mm /
9.21 inch
8 mm /
0.31 inch
STEPCRAFT 420
500 mm /
19.69 inch
324 mm /
12.76 inch
8 mm /
0.31 inch
STEPCRAFT 600
680 mm /
26.77 inch
444 mm /
17.48 inch
8 mm /
0.31 inch
STEPCRAFT 840
920 mm /
36.2 inch
624 mm /
24.57 inch
8 mm /
0.31 inch
5 MACHINE OPERATION
5.1 OPERATOR
WARNING: The improper operation of the machine and its components can result in severe injuries
or material damages. Therefore, please observe the accident prevention regulations!
CAUTION: Before the first use of the machine each operator must have read and understood the existing
instructions for the whole system (machine, system-guided tool, control, software).
5.2 WORK PIECE
The work piece can be directly fixed on the machine table by means of the integrated clamping system.
Alternatively e.g. a steel vice can be fixed on the machine table.
In case of through-milling (cutouts) it is recommended to position a MDF plate with a thickness of 6.0 mm / 0.24
inch underneath the work piece in order to avoid damages on the machine table.
NOTICE: The work piece should be sufficiently fixed in order to avoid unintentional slipping while processing it.
WARNING: Never hold the work piece only with the hand during the processing. There is a severe
risk of injury!
