Admissible work piece size:
Type of machine
Clamping length
Clamping width
STEPCRAFT 210
290 mm /
11.4 inch
210 mm /
8.3 inch
STEPCRAFT 300
380 mm /
14.96 inch
222 mm /
8.74 inch
STEPCRAFT 420
500 mm /
19.69 inch
312 mm /
12.28 inch
STEPCRAFT 600
680 mm /
26.77 inch
432 mm /
17.01 inch
STEPCRAFT 840
920 mm /
24.2 inch
615 mm /
36.2 inch
5.3 SYSTEM-GUIDED TOOLS
CAUTION: Please observe the corresponding operating instructions of your individual tool!
WARNING: Never touch the tool then the system is running! There is a severe risk of injury like cuts,
abrasions, skin burns etc.
5.3.1 DRILLING / MILLING SPINDLE
CAUTION: Switch off the drilling / milling spindle by pressing the corresponding switch (if available) and secure it
against restarting. If the drilling / milling spindle is equipped with a proper mains plug please disconnect it from
the mains!
CAUTION: Always take the milling cutter out of the milling motor when working on the work piece (e.g. clamping,
replacing) otherwise there is a risk that you get injured when touching the milling cutter!
WARNING: Never touch the end mill! There is a severe risk of injury like cuts, abrasions, skin burns
etc.
5.3.2 CUTTING KNIFE
CAUTION: Always take the blade out of the cutting knife when working on the work piece (e.g. clamping,
replacing) otherwise there is a risk that you get injured when touching the blade!
NOTICE: Never touch the tool then the system is running! There is a risk of injury like cuts etc.
5.3.3 HOT CUTTER
CAUTION: Switch off the hot cutter by pressing the corresponding switch (if available). If the hot cutter is
equipped with a proper mains plug please disconnect it from the mains!
WARNING: Never touch/draw the red-hot wire! There is a severe risk of injury like skin burns etc.
5.3.4 ENGRAVING POINT / PLOTTER PEN
NOTICE: Always take the engraving point out of the tool holder when working on the work piece (e.g. clamping,
replacing) otherwise there is a risk that you get injured when touching the engraving point!
5.3.5 3D PRINT HEAD
CAUTION: Switch off the 3D print head by pressing the corresponding switch (if available) and secure it against
loosing hot filament. If the 3D print head is equipped with a proper mains plug please disconnect it from the
mains!
WARNING: Never touch/draw the 3D print head! There is a severe risk of injury like skin burns etc.
