15
An optional pump may be installed to pump material through a wand and spray bar. The
pump may be driven by a gas or diesel engine, or by an electrical or hydraulic system. The
plumbing must be purged of material when finished to prevent plumbing freeze-up. This is
done by reversing the pump to suck the material out of the system. An optional flush tank
may also be installed to further flush the system of any remaining material.
1. Circulate. In this operation, the contents of the tank are pumped through the Recirculate/
Spray valve and directed back to the tank to aid heating and mixing.
a. Set the Recirculate/Spray valve to "Recirculate" position.
b. Set the Product/Flush valve to "Product" position.
c. Engage pump in “Forward” direction.
2. Wand. In this operation, the contents of the tank are pumped to the wand for application
to the road surface.
a. Set the Recirculate/Spray valve to "Spray" position.
b. Set the Product/Flush valve to "Product" position.
c. Set the Wand/Spray Bar valve to "Wand" position.
d. Engage pump in “Forward” direction.
e. Open valve on spray wand handle.
3. Spray Bar. In this operation, the contents of the tank are pumped to the spray bar for ap-
plication to the road surface.
a. Set the Recirculate/Spray valve to "Spray" position.
b. Set the Product/Flush valve to "Product" position.
c. Set the Wand/Spray Bar valve to "Spray Bar" position.
d. Engage pump in “Forward” direction.
4. System Purge. (suck back) In this operation, the pump is “Reversed” to purge the product
from the system.
a. Set the Recirculate/Spray valve to "Spray" position.
b. Set the Product/Flush valve to "Product" position.
c. Set the Wand/Spray Bar valve as needed to suck back the system as desired. (open
valve on wand handle if sucking back the wand)
d. Engage pump in “Reverse” for two minutes.
e. Close valve on wand handle and disengage pump.
OPERATIONS Pumping System w/ Wand & Spray Bar
