Step 7: Press either the up or down key to select the Loop submenu. LOOP will be in the upper
display and SEt will be in the lower display. If this is shown, press the advance key to enter the
Loop submenu. (once in the submenu, use the up or down key to change the parameter values).
Parameter Value Description
7-1 h.Ag on.of heat algorithm
Advance key
7-2 C.Ag off cool algorithm
Advance key
7-3 UfA off user fail action
Advance key
7-4 fAiL off input error failure
Advance key
7-5 LodE no open loop detect enable
Advance key
7-6 rP off ramp action
Advance key
7-7 L.SP 0 degrees low temperature set point(degrees)
Advance key
7-8 h.SP 250 or 550 high temperature set point(degrees)
Advance key
7-9 SP.Lo -100.0 set point, low limit open loop
Advance key
7-10 SP.Hi 100.0 set point, high limit open loop
Advance key
Step 8: Pressing the advance key after parameter SP.hi will return you to the parameter
h.Ag. Press the infinity key once to return to the setup menu.
Step 9: Use the up or down keys to select the output submenu. otPt will be in the upper
display, and SEt will be in lower display. Press the Advance key to enter the
submenu.
Parameter Value Description
(use the up or down key to change parameter values)
9-1 Fn heat Function
Advance key
9-2 o.tb 20.0 time base
Advance key
9-3 O.LO 0% low power scale
Advance key
9-4 o.h1 100% high power scale
Advance key
Step 10: Pressing the advance key after parameter o.h1 will return you to parameter Fn.
Press the infinity key to return to the output submenu.
