Quick Start of T6 AC Servo

Chapter 1 JOG Trail

1.1 Connection

1.1.1 Cables connection.

1.1.2 Connect to tune software. (Perform this step if it is necessary to install

driver)

1.1.2.1 Click in turn “Device Manager”, “Ports (COM&LPT)”, “STEPPERONLINE Driver”,

“Update driver”.

L1/L2: Drive Power Cable Connection

PE: Ground Cable Connection

U/V/W: Motor Power Cable Connection

CN4: Tune Cable Connection

CN3: Encoder Feedback Cable Connection
