Quick Start of T6 AC Servo

Chapter 2 Position Control (Pul + Dir)

2.1 Connection

2.1.1 Cables connection

2.1.1.1 Cover display.

L1/L2: Drive Power Cable Connection

PE: Ground Cable Connection

U/V/W: Motor Power Cable Connection

CN4: Tune Cable Connection

CN3: Encoder Feedback Cable Connection

CN1: Pulse+Direction Cable Connection

CN2: Digital Input/ Output Cable Connection
