SPECIFICATIONS
Interface: A-type Male USB 2.0 Connector
Standards IEEE802.11b; IEEE802.11g
Operating System Windows 2000; Windows XP
Transmission
Distance In door up to 100m, out door up to 300m
(it is limited to the environment).
Radio Data Rate 108/54/48/36/24/12/9/6/11/5.5/2/1 Mbps
(Auto Rate Sensing)
Modulation 1M DBPSK; 2M DQPSK; 5.5M, 11M
CCK; 6M, 9M, 12M, 18M,24M, 36M,
48M, 54M, 108M OFDM;
Media Access Protocol CSMA/CA with ACK
Transmit Power 20dBm (MAX)
Data Security WPA; 64/128/152 BIT WEP; TKIP/AES
Frequency 2.4 ~ 2.4835GHz
Spread Spectrum Direct Sequence Spread Spectrum
(DSSS)
Power Consumption Typically 480mA in full Transmit (TX),
420mA in full Receive (RX)
Physical Environmental
Operating Temp 32°~104°
Storage Temp -40°~158°
Humidity 10% - 95% RH, Non-condensing
Dimensions 3.9×1.2×.4 in
Weight 23g
Product design and specifi cations are subject to change
without previous notice.
