26
20 PAr nonE RS-232C Parity Bit
Selects the parity bit configuration for serial data
interface. Select:
nonE - If no parity bit is used.
odd - If odd parity bit is used.
EvEn - If even parity bit is used.
21 dbitS 8 RS-232C Data Bits
Selects the number of data bits used for serial
RS-232C data interface. Select:
8 - 8 data bits used.
7 - 7 data bits used.
22 rdybSy F Ready/Busy Flow Control
Selects if flow control(hardware handshaking) is to
be used with printer port data interface. Flow
control is used to regulate the flow of data.
Consult the manual of the device being interfaced to
determine if flow control is required. The XC-780
uses low true busy handshaking at the CTS line.
Select:
F - If not using ready/busy flow control.
t - If using ready/busy flow control.
23 FMt Std RS-232C Data Output Format
Selects the format used for serial RS-232 data
output. Select:
Std - If using standard printer format. See the
"RS-232C Output Format" section in the XC780
Technical manual for an example of the
standard printer output format. This
format requires no operator programming.
CuSt - If using the customized printer format
feature. Once selected the actual output
format can be easily programmed to meet the
desired application. See the "Custom Ticket
Format" section in the XC780 Technical
Manual for details on configuring a
custom ticket format.
SPCL - If using the special programmable output
feature of the XC780. This feature gives the
operator complete flexibility in determining
how the XC780 will interface with printers,
computers, and other devices. See the
"Special Programmable Output" section in the
this feature.
24 ProgrM F Program Data Output Format
