Sterling IM30 - Component List

REF# Description IMC24 IMC30 IM24 IM30 IM45 IM60 IM75 INT34 IMI34 IMI68
A Control Valve IMC24VlvAssy IMC30VlvAssy IM24VlvAssy IM30VlvAssy IM45VlvAssy IM60VlvAssy IM75VlvAssy INT34VlvAssy IMI34VlvAssy IMI68VlvAssy
B Mineral Tank MTP1035GR MTP1035GR MTP0844GR MTP0948GR MTP1054GR MTP1248GR MTP1354N MTP1035N MTP0948GR MTP1248GR
C Distributor T04-35 T04-35 TO4-48 TO4-48 T04-54 TO4-48 T04-54 D100S-48 D100S-48 D100S-48
D Resin H075 H10 H075 H10 H10/H05 H10 (X2) H10 (X2)/HO5 FH10 FH10 FH10 (X2)
E 1/4 x 1/8 gravel N/A N/A N/A N/A N/A N/A N/A QC20 QC20 QC25
F Brine Tank Assy. BT1134ASSY BT1134ASSY BT1833ASSY BT1833ASSY BT1833ASSY BT1833ASSY BT1833ASSY BT1134ASSY BT1833ASSY BT1833ASSY
G Overflow fitting BT-OVERFLO BT-OVERFLO BT-OVERFLO BT-OVERFLO BT-OVERFLO BT-OVERFLO BT-OVERFLO BT-OVERFLO BT-OVERFLO BT-OVERFLO
H Safety Brine Valve SBV33ASSY SBV33ASSY SBV33ASSY SBV33ASSY SBV33ASSY SBV33ASSY SBV33ASSY SBV33ASSY SBV33ASSY SBV33ASSY
I Salt Platform BTSG11 BTSG11 BTSG18 BTSG18 BTSG18 BTSG18 BTSG18 BTSG11 BTSG18 BTSG18
Notes: 1.
2.
3.
For unit specifications see "Specifications" on
pages 18-19.
Unit
COMPONENT LIST:
For complete control valve breakdown see
"Replacement Parts" on pages 14-15.
For list of bypass fittings see "Installation Fitting
Assemblies" on pages 16-17.
