IMC24 IMC30 IM24 IM30 IM45 IM60 IM75
MEDIA VOLUME (ft
3
) 0.75 1.0 0.75 1.0 1.5 2.0 2.5
@Minimum Salt Setting (6#/ft
3
) 13,500 18,000 13,500 18,000 27,000 36,000 45,000
@Factory Salt Setting (9#/ft
3
) 15,750 21,000 15,750 21,000 31,500 42,000 52,500
@Maximum Salt Setting (15#/ft
3
) 24,000 32,000 24,000 32,000 48,000 64,000 80,000
SERVICE FLOW RATES (gpm)
Continuous 8 10 8 10 12 15 18
Peak 12 15 12 15 18 20 22
@ Continuous Flow Rate 5 7 7 8 9 10 12
@ Peak Flow Rate 12 20 18 20 20 22 24
REGENERATION FLOW RATES (gpm)
Backwash 2.2 2.2 1.3 1.7 2.2 3.2 4.2
Brine Draw and Slow Rinse 0.27 0.27 0.27 0.27 0.27 0.38 0.38
Rapid Rinse 2.2 2.2 1.3 1.7 2.2 3.2 4.2
FACTORY REGENERATION SETTINGS
Brine Fill (# of salt) 6 9 6 9 13.5 18 22.5
Softening (minutes) 90 90 90 90 90 90 90
Backwash (minutes) 6 6 6 6 8 10 12
Brine & Rinse (minutes) 45 45 45 45 50 55 60
Rapid Rinse (minutes) 4 4 4 4 6 6 6
Total Water Used (gallons) 34 34 25 29 44 72 98
DIMENSIONS (in.)
Mineral Tank (diameter x height) 10 x 35 10 x 35 8 x 44 9 x 48 10 x 54 12 x 48 13 x 54
Brine Tank (diameter x height) 11 x 11 x 34 11 x 11 x 34 18 x 33 18 x 33 18 x 33 18 x 33 18 x 33
Overall (length x width x height) 11 x 21 x 43 11 x 21 x 43 18 x 26 x 52 18 x 27 x 56 18 x 28 x 62 18 x 30 x 56 18 x 31 x 62
GENERAL REQUIREMENTS: Water Temperature
Water Pressure 25 - 100 psi
Electrical Requirements 110v/60hz
Electrical Current Draw 0.5 amps
Maximum Iron Concentration
3
≤ 2.0 ppm
Pressure loss information is approximate. Actual pressure loss may vary
depending on water quality, temperature, gallons used since last regeneration,
etc.
Water softeners can be expected to remove reasonable amounts of clear water
(ferrous) iron only. For best results an iron filter is recommended. Anytime red
water (ferric) iron or iron bacteria is present an iron filter is required.
Unit models listed include 3/4" Q-Tite plumbing connections. If 1" elbow
connections are required use "-1" as suffix to the unit model number (i.e. IM30-1).
