Sterling IM30 - Page 17

Item Part
No. No.
QT-34 KIT 2
1 CV3105 2
2 CV3151 2
3 PEX-L 2
SERVICE WRENCH - CV3193
Although no tools are necessary to assemble
or disassemble the valve, the Service Wrench,
(shown in various positions on the valve) is
available to aid in assembly or disassembly.
Nut, 1" quick connect
PEX tubing insert
INSTALLATION FITTING ASSEMBLIES:
3/4" COPPER Q-TITE CONNECTOR
Description
Qty
Fittings, Items # 1-3
O-ring 215
3
2
1
Loosens Drain Nut In
Polytube Applications
Loosens Injector and
Bypass Caps
Loosens Quick
Connect Nuts
Loosens Drive Cap
17
