A CV3002CC Drive Assembly, IM Series
B CV3186 Power Cord with Transformer, Clack Impression Valve
C CV3003 Meter and Cable Assembly
D CV3006 Bypass Valve, IM Series, less I/O fittings
1 CV3175CC-01GR Gray Front Cover, IM Series
2 CV3107-01 Drive Motor, IM Series
3 CV3108CC Circuit Board, IM Series Valve
4 CV3004 Drive Cap Assembly
6 CV3011 Piston Assembly, IM Series
7 CV3174 Brine Valve, IM Series
8 CV3005 Seal Cartridge Assembly, IM Series
9 CV3178 Back plate for IM Series valve
10 CV3180 Base o-ring for IM Series valve, -337
12 CV3177-01 Injector screen, IM Series
13 CV3010-1Z Injector Assembly Plug
14 CV3010-1E Clack Injector, White (for 1.5 cubic feet and less)
CV3010-1F Clack Injector, Dark Blue (for 2 cubic feet and higher)
15 CV3150 Split Ring Retainer
16 CV3151 Nut, 1" Quick Connect
17 CH4615 Elbow Locking Clip
19 CV3165-01 Refill Flow Control Retainer
20 CH4613 Brine Fitting, 3/8" Tube
21 GL463412 3/4" Female NPT x 1/2" Barb Elbow
22 CV3158-01 Drain Elbow 3/4" Male Assy
23 CV3159-01 DLFC Retainer Assembly
24 Drain Line Flow Control Button:
CV3162-010 Flow Control Washer, 1.0 GPM (for IMI34)
CV3162-013 Flow Control Washer, 1.3 GPM (for INT34)
CV3162-017 Flow Control Washer, 1.7 GPM (for IM24 and IM30)
CV3162-022 Flow Control Washer, 2.2 GPM (for IMC24, IMC30, IM45, and IMI68)
CV3162-032 Flow Control Washer, 3.2 GPM (for IM60 and IM75 )
