1. INTRODUCTION
The HP4750 Stirred Cell is a high-pressure, chemically resistant stirred cell that performs
a wide variety of membrane separations. With a maximum pressure rating of 1000 psig
(69 bar), the HP4750 Stirred Cell is ideally suited for reverse osmosis (RO) filtration,
nanofiltration (NF), ultrafiltration (UF), and microfiltration (MF) separations. Stainless steel
(316L) construction and chemically resistant components make the HP4750 Stirred Cell an
ideal choice to filter aqueous and non-aqueous solutions.
Table 1 outlines the operational parameters and technical specifications of the HP4750
Cell.
Prior to operating or servicing this device, this manual must be read and understood.
Table 1: HP4750 Features and Technical Specification
Parameter Description
Membrane Size 47-49 mm diameter (1.93 inches)
Active Membrane Area 14.6 cm
2
(2.26 in
2
)
Processing Volume 300 mL
Hold-Up Volume 1 mL
Maximum Pressure 69 bar (1000 psig)
Maximum Temperature 121 °C (250 °F) at 55 bars (800 psig)
Maximum Torque Setting for Nuts 20 ft-lbs
pH Range Membrane Dependant
Connections
Permeate Outlet ⁄ inch diameter 316L SS tubing
Pressure Inlet ¼ inch FNPT
Wetted Materials of Construction
Cell Body 316L Stainless Steel
O-Rings Buna-N, others available as options
Gasket Buna-N, others available as options
Stir Bar PTFE-coated magnet
Dimensions
Cell Diameter 5.1 cm (2.0 inches)
Cell Height 22.4 cm (10.0 inches)
Autoclavable Ye s
Sterlitech Corporation | HP4750 Cell Manual
1
