8.EXPLODED VIEW WITH PARTS LIST (OUTPUT UNIT)
FOR ALL MODELS
282
EN
Part No. Description Part No. Description Part No. Description
1 wire retainer 46 locking screw
3 clamp 48 screw M6×20
4 nut M5 49 left handle
5 screw M5×22 50 handle bar
6 suspension ring 51 drive shaft
7
rear drive shaft tube
assembly
52
bush
8 rear drive shaft tube 53 screw M6x30
9 support ring 54 bottom supporting block
10 connector 55 nut M6
11 screw M5×25 56 upper supporting block
12 screw M5×12 57 supporting spring
13 screw M6×50 58 bottom clamp
14 plate washer 6 59 lock spring
15 lock handle 60 upper clamp
16 nut M6 61 plate washer 6
17 locking pin 62 lock screw
18
front drive shaft tube
assembly
63
right handle assembly
19 front drive shaft tube 64 screw M5×30
20 support ring 65 plate washer 5
21 gear box assembly 66 right handle left cover
22 circlip for shaft 10 67 throttle trigger lockout
23 circlip for hole 26 68 wire pipe
24 bearing 6000 69 interrupted wire
25 drive gear 70 ground wire
26 gear box 71 throttle cable
27 top protective cover 72 nut M5
28 screw M5×8 73 tapping screw ST3.5×9.5
29 bearing 6000 74 tapping screw ST4.2×10
30 driven gear 75 right handle right cover
31 output shaft 76 throttle trigger spring
32 bearing 6002 77 throttle trigger
33 circlip for hole 26 78 torsion spring
34 top clamping plate 79 switch
35 bottom clamping plate 80 blade transport cover
36 bottom
protecting cap 81 trimmer head
3
7 nut M10×1.25-L 82 blade
38 screw M6×12
39 screw M6×12
40 screw M6×25
41 drive shaft
42 extended guard
43 tapping screw ST4.8×13
44 line-limiting device
45 cutting attachment guard
