< 11 >
10 Snap ring - C type 33N1-H4200 1 ea Φ 42
11 Ball bearing 33N2-Z6004 2 ea #6004ZZ
12 Hexagon socket head 33W1-1B855 1 ea M8 x 5 5 L (SEMS)
13 Nut-nylon insert lock 33N1-L0800 1 ea M8
14 Tensioner spring 32M2-T80T1 1 ea
15 Hexagon socket head 33W1-1B815 2 ea M8 x 1 5 L (SEMS)
3-5 Assembly Rear Roller (#4)
3-5 Description
No Parts
Parts No. Q ’ TY Remark
1 Rear roller pipe 32M2-TW401 1 ea
2 Rear roller shaft 32M2-TW701 1 ea
3 Ball bearing 33N2-D6305 2 ea #6305DD
4 Snap ring - C type 33N1-S2500 2 ea Φ 25
5 Snap ring - C type 33N1-R6200 2 ea Φ 62
To Next Page
