stex S25T - Accompanying Parts and Tools

< 37 >
Accompanying parts
No Parts Q ’ TY
Models
S 25T S25TX S25TXi
1
Master main frame
1
○ ○ ○
2
Display support R
1 ○ ○ ○
3
Display support L
1 ○ ○ ○
4
Hexagon socket head // (SEMS) M8x20L
10 ○ ○ ○
5
Display console assembly
1 ○ ○ ○
6
Hexagon socket head // (SEMS) M8x20L
4
○ ○ ○
7
Display top assembly
1
○ ○ ○
8
Hexagon socket head // (SEMS) M8x 5 0L
4 ○ ○ ○
Tools required for assembly
Screw driver, 6mm L-wrench, 17 ” Spanner
