1 Display board 22BD-TS11E 1 ea
2 S _ Display data cable 32Q1-TS181 1 ea
3 S _ Display key cable 32Q1-TS171 1 ea
4 Membrane overlay 32P5-TS011 1 ea
3-21-2 Top Circuit Diagram – S25TX
3-21-2 Description
No Parts
Parts No. Q ’ TY Remark
1 LCD monitor 33F3-LS001 1 ea
To Next Page
