stex S25T - Main Frame Assembly (#7)

< 14 >
3-8 Assembly Main Frame (#7)
3-8 Description
No Parts
Parts No. Q ’ TY Remark
1 Main frame assembly 32M1-TS005 1 ea
2 Incline leg assembly 32M1-TSL03 1 ea
3 Front wheel for S25T 33N5-M0160 2 ea
4 Hexagon socket head 33W1-1B815 2 ea M8 x 15 L (SEMS)
5 Oil less bearing for S25T 32N2-O2040 2 ea
6 Leg washer 32M1-T80V1 2 ea
7 Bearing shaft for S25T 32M2-TSL20 2 ea
8 Washer-split lock 33N1-P1200 2 ea Φ 12
