3-11 Assembly Display Frame (#3)
3-11 Description
No Parts
Parts No. Q ’ TY Remark
1 Display bottom case 32M3-TS141 1 ea
2 COMM board 22BD-TS15D 1 ea
3 COMM fix bracket 32M1-TSV01 1 ea Φ 5 x 16 L
4 Machine pan head 33T6-1B408 2 ea M 4 x 8L (SEMS)
5 Tapping truss head 33U6-6Z512 2 ea Φ 5 x 12L
