3-13 Assembly Display Frame (#5)
3-13 Description
No Parts
Parts No. Q ’ TY Remark
1 Display middle case 32M3-TS131 1 ea
2 Emergency switch 32M3-TS161 1 ea
3 Emergency fix bracket 32M3-TS151 1 ea
4 Micro switch 33H1-TS011 1 ea
5 Tapping truss head 33U6-6Z520 2 ea Φ 5 x 20L
6 Tapping truss head 33U6-6Z516 1 ea Φ 5 x 16 L
7 Multi board bracket 323M-TS171 1 ea
8 IPOD cable 32Q1-TS1M1 1 ea
9 Front board 22BD-TS14A 1 ea
