3-18-2 Assembly Display Frame – S25TX (#10)
3-18-2 Description
No Parts
Parts No. Q ’ TY Remark
1 Display top front panel (15 ” LCD) 32M3-TSX71 1 ea
2 15 ” LCD panel 33F3-L0151 1 ea
3 LCD guide panel (15 ” ) 32M2-TS0U1 1 ea
4 15 ” br acket 32M1-TSX32 1 ea
5 LCD back plate _ LH(RH) 32M1-TSXC1/D1 1 set
6 Inverter board 22BD-TS121 1 ea
To Next Page
