11 Hexagon socket head 33W1-1B820 16 ea M8 x 20 L (SEMS),
⑧
,
⑩
12 Hexagon socket head 33W1-1B820 4 ea M8 x 20 L (SEMS), ② , ⑥
13 Tapping truss head 33U6-6Z512 4 ea Φ 5 x 12 L , ④
14 Machine pan head 33T6-1B512 4 ea M5 x 12 L , ③
3-3-1 Assembly Main Frame (#2) – S25T
