INSTALLATION
Specication
38 | DHB-E LCD www.stiebel-eltron.com
GUARANTEE
17.3 Domestic hot water output
The DHW output is subject to the connected power supply, the
appliance's connected load and the cold water inlet temperature.
The rated voltage and rated output can be found on the type plate.
Connected load in kW 38°C DHW output in l/min
Rated voltage Cold water inlet temperature
380V 400V 415V 5°C 10°C 15°C 20°C
9.9 4.3 5.1 6.1 7.9
12.2 5.3 6.2 7.6 9.7
11 4.8 5.6 6.8 8.7
13.5 5.8 6.9 8.4 10.7
11.8 5.1 6.0 7.3 9.4
14.5 6.3 7.4 9.0 11.5
16.2 7.0 8.3 10.1 12.9
18 7.8 9.2 11.2 14.3
19.4 8.4 9.9 12.0 15.4
16.2 7.0 8.3 10.1 12.9
19 8.2 9.7 11.8 15.1
21.7 9.4 11.1 13.5 17.2
18 7.8 9.2 11.2 14.3
21 9.1 10.7 13.0 16.7
24 10.4 12.2 14.9 19.0
19.4 8.4 9.9 12.0 15.4
22.6 9.8 11.5 14.0 17.9
25.8 11.2 13.2 16.0 20.5
Connected load in kW 50°C DHW output in l/min
Rated voltage Cold water inlet temperature
380V 400V 415V 5°C 10°C 15°C 20°C
9.9 3.1 3.5 4.0 4.7
12.2 3.9 4.4 5.0 5.8
11 3.5 3.9 4.5 5.2
13.5 4.3 4.8 5.5 6.4
11.8 3.7 4.2 4.8 5.6
14.5 4.6 5.2 5.9 6.9
16.2 5.1 5.8 6.6 7.7
18 5.7 6.4 7.3 8.6
19.4 6.2 6.9 7.9 9.2
16.2 5.1 5.8 6.6 7.7
19 6.0 6.8 7.8 9.0
21.7 6.9 7.8 8.9 10.3
18 5.7 6.4 7.3 8.6
Connected load in kW 50°C DHW output in l/min
Rated voltage Cold water inlet temperature
380V 400V 415V 5°C 10°C 15°C 20°C
21 6.7 7.5 8.6 10.0
24 7.6 8.6 9.8 11.4
19.4 6.2 6.9 7.9 9.2
22.6 7.2 8.1 9.2 10.8
25.8 8.2 9.2 10.5 12.3
17.4 Application areas/ Conversion table
Specific electrical resistance and specific electrical conductivity
Standard specifica-
tion at 15°C
20°C
25°C
Resist-
ance
ρ≥
Conductivity σ≤
Resist-
ance
ρ≥
Conductivity σ≤
Resist-
ance
ρ≥
Conductivity σ≤
Ωcm mS/m μS/cm Ωcm mS/m μS/cm Ωcm mS/m μS/cm
900 111 1111 800 125 1250 735 136 1361
17.5 Pressure drop
Taps/valves
Tap pressure drop at a flow rate of 10 l/min
Mono lever mixer tap, approx. MPa 0.04 - 0.08
Thermostatic valve, approx. MPa 0.03 - 0.05
Shower head, approx. MPa 0.03 - 0.15
Sizing the pipework
When calculating the size of the pipework, an appliance pressure
drop of 0.1MPa is recommended.
17.6 Fault conditions
In the event of a fault, loads up to 80°C at a pressure of 1.0 MPa
can occur briefly in the installation.
17.7 Test symbols
See type plate on the appliance.
17.8 Energy consumption data
The product data complies with EU regulations relating to the
directive on the ecodesign of energy related products (ErP).
DHB-E 11/13 LCD DHB-E 18 LCD 25A DHB-E 18/21/24 LCD DHB-E 27 LCD
236743 236744 236745 236746
Manufacturer STIEBEL ELTRON STIEBEL ELTRON STIEBEL ELTRON STIEBEL ELTRON
Load profile S S S S
Energy efficiency class A A A A
Energy conversion efficiency % 39 39 39 39
Daily power consumption kWh 2,211 2,211 2,211 2,217
Annual power consumption kWh 480 480 480 481
Default temperature setting °C 60 60 60 60
Sound power level dB(A) 15 15 15 15
Special information on measuring effi-
ciency
Measured with integral flow
limiter, maximum output and
maximum set value
Measured with inte-
gral flow limiter and
maximum set value
Measured with integral flow limiter
with highest flow rate, maximum
output and maximum set value
Measured with integral
flow limiter and maxi-
mum set value
