STIEBEL ELTRON DHE Connect 18 User Manual

INSTALLATION
Service information
98 |DHEConnect | DHETouch www.stiebel-eltron.com
Connection overview/ Component overview
D0000053288
1
2
3
4
5
6
7
8
9
10
1 Motorised valve
2 Flow sensor
3 High limit safety cut-out, automatic reset
4 NTC sensor
5 Wireless module
6 Display
7 Programming unit
8 Connected load button
9 Diagnostic traffic light
10 "Service" button to enable "Anti-scalding protection
activation"
Wireless module connecting cable plug positions
D0000056236
Programming unit connecting cable plug positions
T-Soll
D0000056909
1
1 "T-Soll"
