STIEBEL ELTRON WPC 07 cool User Manual

64 | WPC | WPC cool www.stiebel-eltron.com
INSTALLATION
Specication
18.9 Data table WPC...
Output details apply to new appliances with clean heat exchangers.
The power consumption figures for the integral auxiliary drives are maximum values and may vary subject to operating point.
The power consumption of the integral auxiliary drives is included in the output details of the heat pump (to EN 14511).
WPC 04 WPC 05 WPC 07 WPC 10 WPC 13
232926 232927 232928 232929 232930
Outputs to EN 14511
Output at B0/W35 (EN 14511) kW 4.77 5.82 7.50 10.31 13.21
Power consumption
Power consumption, emergency/booster heater kW 8.8 8.8 8.8 8.8 8.8
Max. power consumption, circulation pump, source side W 76 76 130 130 130
Max. power consumption, circulation pump, heating side W 45 45 45 72 72
Power consumptions to EN 14511
Power consumption at B0/W35 (EN 14511) kW 1.06 1.21 1.55 2.05 2.73
Coefficients of performance to EN 14511
Coefficient of performance at B0/W35 (EN 14511) 4.52 4.79 4.85 5.02 4.83
Sound data
Sound power level (EN 12102) dB(A) 42 43 44 48 50
Sound pressure level at 1 m distance in a free field dB(A) 34 35 36 40 42
Sound pressure level at 5 m distance in a free field dB(A) 20 21 22 26 28
Application limits
Permissible operating pressure, cylinder MPa 1 1 1 1 1
Min. application limit on the heating side °C 15 15 15 15 15
Max. application limit on the heating side °C 60 60 60 60 60
Heat source application limit (min.) °C -5 -5 -5 -5 -5
Heat source application limit (max.) °C 20 20 20 20 20
Water hardness °dH ≤3 ≤3 ≤3 ≤3 ≤3
pH value (with aluminium compounds) mg/l 8.0-8.5 8.0-8.5 8.0-8.5 8.0-8.5 8.0-8.5
pH value (without aluminium compounds) mg/l 8.0-10.0 8.0-10.0 8.0-10.0 8.0-10.0 8.0-10.0
Chloride mg/l <30 <30 <30 <30 <30
Conductivity (softening) μS/cm <1000 <1000 <1000 <1000 <1000
Conductivity (desalinating) μS/cm 20-100 20-100 20-100 20-100 20-100
Oxygen 8-12 weeks after filling (desalinating) mg/l <0.1 <0.1 <0.1 <0.1 <0.1
Oxygen 8-12 weeks after filling (softening) mg/l <0.02 <0.02 <0.02 <0.02 <0.02
Hydraulic data
Cylinder capacity l 175 175 175 162 162
Available external pressure differential; heat source hPa 610 630 755 660 395
Available external pressure differential, heating system hPa 690 525 465 440 180
Electrical details
Rated compressor voltage V 400 400 400 400 400
Frequency Hz 50 50 50 50 50
Fuse - compressor A 3 x C 16 3 x C 16 3 x C 16 3 x C 16 3 x C 16
Control circuit fuse A 1 x B 16 1 x B 16 1 x B 16 1 x B 16 1 x B 16
Emergency/booster heater fuse A 3 x B 16 3 x B 16 3 x B 16 3 x B 16 3 x B 16
Compressor phases 3/N/PE 3/N/PE 3/N/PE 3/N/PE 3/N/PE
Control phases 1/N/PE 1/N/PE 1/N/PE 1/N/PE 1/N/PE
Phases, emergency/booster heater 3/N/PE 3/N/PE 3/N/PE 3/N/PE 3/N/PE
Rated control voltage V 230 230 230 230 230
Rated voltage, emergency/booster heater V 400 400 400 400 400
Current (with/without softstarter) A 28 28 <30 <30 <30
Versions
Refrigerant R410 A R410 A R410 A R410 A R410 A
Refrigerant capacity kg 1.05 1.40 1.90 2.25 2.30
Compressor oil Emkarate RL 32
3MAF
Emkarate RL 32
3MAF
Emkarate RL 32
3MAF
Emkarate RL 32
3MAF
Emkarate RL 32
3MAF
Condenser material 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu
Evaporator material 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu
Type circulation pump heating side Yonos PARA
25/7.0
Yonos PARA
25/7.0
Yonos PARA
25/7.0
Yonos PARA
25/7.5
Yonos PARA
25/7.5
Type circulation pump soruce side Yonos PARA RS
25/7.5 PWM GT
Yonos PARA RS
25/7.5 PWM GT
Stratos PARA
25/1-8
Stratos PARA
25/1-8
Stratos PARA
25/1-8

STIEBEL ELTRON WPC 07 cool Specifications

General

Brand	STIEBEL ELTRON
Model	WPC 07 cool
Category	Heat Pump
Language	English
