WORKSHOP MANUAL
EDITION
PAGE
13 /
124
Engage the parking brake and place two wedges behind the rear wheels
to prevent the machine from moving.
▶▶
– Raise the machine using a jack that acts under the front transmis-
sion assembly.
– Stabilize the machine with
two stands placed in corre-
spondence of load-bearing
elements of the front part of
the frame.
▶▶
– Place a wooden beam under the two lower
brackets of the frame, and where the axis of
the front wheels are
– Lift the machine using a jack that acts in the
centre of the beam.
– Stabilize the machine with two stands
placed in correspondence of load-bearing
elements of the front part of the frame.
