16 EN
4. INSTALLATION
4. INSTALLATION
4.1. GENERAL INSTALLATION INFORMATION
CAUTION:
Do not modify, tamper with, elude or eliminate the safety devices installed.
NOTE: For further clarication on the installation of the product please contact a STIGA dealer.
4.2. INSTALLATION COMPONENTS
(A) charging base
(B) Power supply
(C) Reference Satellite Station
(D) Fixing screws for the charging base
(E) Bracket for the separate fastening of the satellite reference station
(F) Power Supply for the separate installation of the Reference Satellite Station (optional)
(G) 5m extension cable
(H) Mobile device (not included)
See Chapter 9 “Accessories”
A
C
F
B
E
H
D
G
