18 EN
4. INSTALLATION
WARNING:
The power cable (B), power supply unit, extension cord and all other electric
cables which do not belong to the product must remain outside the cutting area
cables which may come into contact with live parts.
• The return to the base of the robot lawn mower takes place via a virtual return path, which includes
a manoeuvring zone extending 1 m to the right and 1 m to the left of the recorded path (A), and 50
cm behind the docking station (B). The following minimum distances between the manoeuvring area
and the various garden elements must be observed:
- 30 cm from obstacles conned by virtual perimeters or no-cut zones (C)
- 30 cm from xed obstacles without connes or continuous structural elements (D);
- 1m from public roads (E);
- 1m from pools (F);
- 1m from footpaths (G);
- 1m from clis or steep slopes (H).
A
2 m
3 m
B
