ZT 3107 T
Chapter
5 -
STEERING SYSTEM - TRANSMISSION - WHEELS
2017
5.1 STEERING SYSTEM (DIRECTION OF TRAVEL)
5.1.1 General information
• Ergonomic adjustment
• Adjusting the direction of travel
5.1.2 Ergonomic adjustment of the levers
a) Adjustment of the height and the longitu-
dinal position
WARNING! The lever must always be fixed
by two screws.
Summary
5.1 STEERING SYSTEM (DIRECTION OF TRAVEL) ...............................20
5.2 TRANSMISSION .................................................................................22
5.3 WHEELS AND TYRES ........................................................................29
5 - STEERING SYSTEM - TRANSMISSION - WHEELS
1
1
2
3
