ZT 3107 T
Chapter
5 -
STEERING SYSTEM - TRANSMISSION - WHEELS
2017
5.2.2 Adjusting maximum operating speed
NOTE The hydrostatic transmission units have
a predetermined range of use, given by the sum
of the maximum speeds in forward and reverse
gear Therefore, any increase of either of the two
parameters reduces the other, and vice versa.
NOTEThe default factory setting for this centre distance is 338 mm which allows the machine to
reach the speeds required for optimal performance
5.2.3 Replacing the shock absorber
NOTE Given the difficulty in accessing the lower
pin retaining nut, we recommend leaving it in its
seat and using it to attach the one supplied as
replacement.
NOTE Always replace one shock absorber at a
time.
a) Left shock absorber
1
1
2
1
3
3
4
5
