Stihl 410 User Manual

Original Instruction ManualPrinted on chlorine-free paper
Printing inks contain vegetable oils, paper can be recycled.
© ANDREAS STIHL AG & Co. KG, 2010 0458-370-8221-E. M4-5.G10.FST. 0000000894_005_GB
TS 410, TS 420
English
1
{
Contents
Dear Customer,
Thank you for choosing a quality
engineered STIHL product.
This machine has been built using
modern production techniques and
comprehensive quality assurance.
Every effort has been made to ensure
your satisfaction and troublefree use
of the machine.
Please contact your dealer or our
sales company if you have any
queries concerning your machine.
Your
Hans Peter Stihl
Guide to Using this Manual 2
Safety Precautions and Working
Techniques 2
Sample applications 10
Cutting wheels 12
Composite resin cutting wheels 13
Diamond cutting wheels 13
Electronic water control 16
Assembling the cast arm and guard 17
Tensioning the ribbed V-belt 21
Fitting / replacing an abrasive
wheel 22
Fuel 23
Fueling 24
Starting / Stopping the Engine 25
Air Filter System 27
Engine Management 28
Adjusting the Carburetor 28
Spark Arresting Screen in Muffler 29
Checking the Spark Plug 30
Replacing the Starter Rope and
Rewind Spring 31
Replacing the V-belt 33
Cut-off machine cart 34
Storing the Machine 34
Maintenance and Care 35
Main Parts 37
Specifications 39
Special Accessories 40
Maintenance and Repairs 40
STIHL Limited Emission Control
Warranty Statement 41

Stihl 410 Specifications

General

Power Source	Gasoline
Engine	2-stroke
Vibration Level	3.9 m/s²
Sound Power Level	109 dB(A)
Displacement	66.7 cc
Spindle Arbor	20 mm
