TS 410, TS 420
English
39
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
Engine
STIHL single cylinder two-stroke engine
TS 410
TS 420
Ignition system
Electronic magneto ignition
(breakerless)
This ignition system fulfills all
requirements of the Canadian
Interference-Causing Equipment
Regulations ICES-002.
Fuel system
All position diaphragm carburetor with
integral fuel pump
Air filter
Main filter (paper filter) and flocked wire
mesh auxiliary filter
Weight
Abrasive wheels
The quoted maximum permissible
operating speed of the abrasive wheel
must be greater than or equal to the
maximum spindle speed of the cut-off
machine used.
Abrasive wheels (TS 410)
Abrasive wheels (TS 420)
Specifications
A = 300 hours
B = 125 hours
C = 50 hours
Displacement: 66.7 cm
3
Bore: 50 mm
Stroke: 34 mm
Engine power to
ISO 7293:
3.2 kW (4.4 HP)
at 9000 rpm
Idle speed: 2500 rpm
Max. spindle speed: 5350 rpm
Displacement: 66.7 cm
3
Bore: 50 mm
Stroke: 34 mm
Engine power to
ISO 7293:
3.2 kW (4.4 HP)
at 9000 rpm
Idle speed: 2500 rpm
Max. spindle speed: 5350 rpm
Spark plug
(suppressed): Bosch WSR 6 F
Electrode gap: 0.5 mm
Fuel tank capacity: 0.71 l
Weight without abrasive wheel, with
water attachment, without fuel
TS 410: 9.4 kg
TS 420: 9.6 kg
Weight without abrasive wheel, with
electronic water control, without fuel
TS 410: 9.9 kg
TS 420: 10.1 kg
Outside diameter: 300 mm
Hole diameter/spindle
diameter: 20 mm
Tightening torque: 30 Nm
Composite resin abrasive wheels
Minimum outside diameter of
front thrust washer: 103 mm
Max. depth of cut: 100 mm
Diamond abrasive wheels
Minimum outside diameter of
front thrust washer: 103 mm
Max. depth of cut: 100 mm
Outside diameter: 350 mm
Hole diameter/spindle
diameter: 20 mm
Tightening torque: 30 Nm
Composite resin abrasive wheels
Minimum outside diameter of
front thrust washer: 103 mm
Max. depth of cut: 125 mm
