: Position blade (7) on the thrust
plate (8).
Collar (see arrow) must engage
hole in blade.
: Fit thrust washer (4) on the shaft (9).
: Block the shaft.
: Screw the nut (6) on to the shaft
counterclockwise and tighten down
firmly.
If the cup spring (10) on the nut (6)
becomes fatigued, install a new nut.
Starting the engine
Always follow the starting procedure
described in the owner’s manual of the
basic power tool you are using.
: Make sure you have a firm footing.
Check that the edger blade is not
touching the ground or any other
obstacles!
: Hold the unit securely and press it
firmly against the ground with your
left hand.
If you start the engine in the START
positon, the edger blade may begin
to rotate as soon as the engine runs.
Do not run the engine for any longer
than necessary in the starting
throttle position.
To shut down the engine:
: Move the slide control in direction of
arrow ( h ) to STOP – $ or move
the stop switch to $.
6
10
8
9
241BA012 KN
7
4
7
Starting / Stopping
the Engine
406BA007 KN
406BA008 KN
