FS 87, FS 87 R
English
22
Threaded filler cap
Opening the cliplock filler cap
N Swing the clip into an upright
position
N Turn the cap counterclockwise
(approx. 1/4 turn)
N Remove the filler cap
Refueling
Take care not to spill fuel while fueling
and do not overfill the tank. STIHL
recommends use of the STIHL filling
system (special accessory).
Closing the cliplock filler cap
N Position the cap with the clip in an
upright position; the markings must
line up
N Turn cap clockwise as far as it will
go (approx. 1/4 turn)
N Fold the cliplock down so that it is
flush with the surface
If the cliplock is not flush with the surface
and the lug on the clip does not engage
entirely in the recess (arrow), the cap is
not properly closed and the steps
described above must be repeated.
Opening screw-type tank cap
N Turn the cap counterclockwise until
it can be removed from the tank
opening.
N Remove the cap.
Filling up with fuel
Take care not to spill fuel while fueling
and do not overfill the tank. STIHL
recommends you use the STIHL filler
nozzle (special accessory).
Closing screw-type tank cap
N Place the cap in the opening.
N Turn the cap clockwise as far as
stop and tighten it down as firmly as
possible by hand.
