0458-713-8221-A
32
English
24 Specifications
24.1 STIHL FSA 56
Intended for household use.
– Approved battery type: STIHL AK series
– Weight without deflector and cutting attachment:
4.6 lbs. (2.1 kg)
– Length: 58 in. to 66 in. (1470 mm to 1670 mm)
24.2 STIHL AK Series Battery
Approved charger type: STIHL AL 101, AL 300 or AL 500
series.
– Battery technology: Lithium-Ion
– Voltage: 36 V
– Capacity in Ah: See rating plate
– Energy content in Wh: See rating plate
– Weight in kg: See rating plate
– Permissible ambient temperature range during use or
storage: 14 °F to 122 °F (- 10 °C to 50 °C)
For a complete list of approximate charging times, see
www.stihl.com/charging-times.
24.3 STIHL AL 101
– Mains voltage: 120 V
– Rated current: 1.3 A
– Frequency: 60 Hz
– Charging current: 1.5 A
– Rated power: 75 W
– Insulation: Class II (Double Insulation)
– Permissible ambient temperature range during charging:
41 °F to 104 °F (5 °C to 40 °C)
24.4 Symbols on the Trimmer, Battery and Charger
24 Specifications
Symbol Explanation
VVolt
Hz Hertz
A Ampere
Ah Ampere hour
WWatt
Wh Watt hour
AC Alternating current
IP20 Degree of electrical protection
Push and hold the retaining latch in this direction
to unlock.
Push and hold the drive tube release button to allow
length adjustment.
Rated speed of the cutting attachment
Direct current
Number of cells and energy content according to cell
manufacturer's specification. The energy content
available in specific applications is lower.
Mark of the CSA-Group.
STIHL products must not be disposed of in the
household trash, but only in accordance with local,
state and federal laws and regulations and as
provided in this manual, @ 27.
The RBRC seal indicates that STIHL has prepaid for
battery recycling.
Insulation: Class II (Double Insulation)
Use and store charger only indoors in dry rooms.
