EN
17
0478 201 8314 C - EN
Soft material:
Organic plant trimmings such as fruit and
vegetable waste, flower cuttings, leaves,
etc.
Hard material:
Tree and hedge cuttings and thick branch
material with side shoots.
8.2 What material cannot be
processed?
Stones, glass, bits of metal (wire, nails,
etc.) or plastic must not be fed into the
garden shredder.
As a general rule:
Any materials that do not belong on the
compost heap should not be processed
using the garden shredder.
8.3 Maximum branch diameter
The data relates to freshly cut branch
material:
Maximum branch diameter:
GHE 355: 35 mm
8.4 Working area for operator
For safety reasons the operator must stay
in the working area (grey area) for the
entire operating period.
To ensure you are not hit by shredded
material that is ejected backwards, you
should not stand directly behind the
garden shredder but slightly to the side of
it (hatched area A).
8.5 Correct way to feed the garden
shredder
Tree and hedge cuttings should be
processed when fresh, as the
shredding performance is better
with fresh than with dried-out or wet
material.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Stihl GHE 355 and is the answer not in the manual?

Stihl GHE 355 Specifications

General IconGeneral
Power2500 W
Product colorBlack, Orange, White
Uncertainty K2.4 dB
Cutting systemBlade
AC input voltage230 V
Transport wheelsYes
Rated speed (max)2750 RPM
Sound power level100 dB
Material throughput- kg/h
Sound pressure level94 dB
Collection box capacity- L
Maximum branch thickness35 mm
Weight and Dimensions IconWeight and Dimensions
Weight30000 g
