Stihl HSA 45 User Manual

0458-717-8221-A
29
English 22 Specifications
22.1 STIHL HSA 45
Intended for household use.
– Weight: 5.3lbs.(2.4kg)
– Battery technology: Lithium-Ion
– Voltage: 18 V
– Rated capacity in Ah
1
: See rating plate
– Stored energy in Wh
2
: See rating plate
– Permissible ambient temperature range during use or
storage: 32°F to 122°F (0°C to 50°C)
If the hedge trimmer is used or stored at ambient
temperatures above 86°F (30°C), its runtime and
performance may be reduced.
22.2 Cutting Blades
– Tooth spacing: 0.95in.(24.1mm)
– Cutting length: 19.7in. (500mm)
– Sharpening angle: 32°
22.3 STIHL LK 45
– Mains voltage: 100V to 240V
– Rated current: 0.4A
– Frequency: 50/60Hz
– Charging current: 0.65A
– Rated power: 14.6W
– Insulation: Class II (Double Insulation)
– Permissible ambient temperature range during charging:
32°F to 104°F (0°C to 40°C)
Ambient temperatures above 86°F (30°C) may increase
charging times.
22.4 Symbols on the Hedge Trimmer and Charger
22 Specifications
1
Rated capacity calculated pursuant to IEC 61960. Usable energy
available to the operator will be less.
2
The battery is marked with its stored energy as provided by the cell
manufacturer. Usable energy available to the operator will be less.
Symbol Explanation
VVolt
Hz Hertz
A Ampere
Ah Ampere hour
Wh Watt hour
DC Direct current
AC Alternating current
Push and hold the retaining latch in this direction
to unlock
Direct current
Polarity of coaxial output connector.
Number of cells and stored energy according to cell
manufacturer's specification. Usable energy will be
less.
Certification/listing mark of Intertek
Certification/listing mark of CSA
STIHL products must not be disposed of in the
household trash, but only in accordance with local,
state and federal laws and regulations and as
provided in this manual, @ 24.
The RBRC seal indicates that STIHL has prepaid for
battery recycling

Stihl HSA 45 Specifications

General

Blade size	500 mm
Blade type	Double blade
Idle speed	2500 RPM
Product color	Black, Grey, Orange
Sound power level	83 dB
Vibration emission	1.5 m/s²
Sound pressure level	75 dB
Engine power	- W
Power source	Battery
Battery voltage	18 V

Weight and Dimensions

Depth	910 mm
Weight	2300 g
