Stihl HT 131 Instruction Manual

HT 100, HT 101, HT 130, HT 131
English
25
Full harness (HT 100, HT 101 only)
N Put on the full harness (1) and
sling (2) as described in the
instruction sheet provided.
N Adjust the harness and thigh
strap (3) as required.
N Rest the powerhead in the sling
during cutting work.
HT 100, HT 130 only
N Put the backpack carrying
system (1) on your back and adjust
it as described in the instruction
sheet provided.
N Attach the carabiner (2) to the
machine's carrying ring.
N Attach the pole pruner to the
carrying strap when cutting.
N Adjust the hip belt (3), both shoulder
straps (4) and the carrying strap (5).
386BA012 KN
2
1
3
Backpack Carrying System
246BA015 KN
1
2
246BA016 KN
4
5
3

Stihl HT 131 Specifications

General

Engine Power	1.4 kW (1.9 bhp)
Displacement	36.3 cc
Sound Power Level	106 dB(A)
Overall Length	270 - 390 cm
Guide Bar Length	30 cm
Power Source	Gas
Chain Pitch	3/8"
Chain Gauge	1.3 mm
