HT 100, HT 101, HT 130, HT 131
English
27
Symbol on slide control
7 h – stop symbol and arrow. To stop
the engine, push the slide control in
the direction of the arrow on the stop
symbol (h) to STOP-0.
Starting
N Press down the trigger lockout lever
and squeeze the throttle trigger
N and hold them in that position.
N Move the slide control to START
and hold it there.
N Now release the throttle trigger,
slide control and trigger lockout in
that order. This is the starting
throttle position.
N Set the choke knob (8):
N Press the manual fuel pump
bulb (9) at least five times – even if
the bulb is filled with fuel.
Cranking
N Remove the chain scabbard. Check
that the chain is not touching the
ground or any other obstacles.
N Place the unit on the ground: It must
rest securely on the engine support
and the hook. If necessary, rest the
hook on a raised support (e.g. a
branch, mound or something
similar).
WARNING
Check that nobody is standing within the
working range of the pruner.
N Make sure you have a safe and
secure footing.
N Hold the unit with your left hand on
the fan housing and press it down
firmly – your thumb should be under
the fan housing.
NOTICE
Do not stand or kneel on the drive tube.
This will bend the drive tube and may
result in permanent damage.
Alternative method:
N Remove the chain scabbard.
Position the drive tube on a branch
so that it is held by the hook.
N Hold the unit firmly with your left
hand on the fan housing – your
thumb should be under the fan
housing.
N Hold the starter grip with your right
hand.
N Pull the starter grip slowly until you
feel it engage and then give it a brisk
strong pull.
NOTICE
Do not pull out the starter rope all the
way – it might otherwise break.
g if the engine is cold
e for warm start – also use this posi-
tion if the engine has been running
but is still cold.
