KM 111 R, KM 131 R
English
16
Starting the Engine
N Press the manual fuel pump
bulb (9) at least five times – even if
the bulb is already filled with fuel.
N Press in the choke knob (8) and turn
it to the position that suits the engine
temperature:
The choke knob must engage in
position.
Cranking
N Place the power tool on the ground
so that it rests on the machine
support: Check that the working tool
is not touching the ground or any
other obstacles – see also "Starting
/ Stopping the Engine" in the
KombiTool instruction manual.
N Make sure you have a safe and
secure footing.
N Hold the unit with your left hand and
press it down firmly – your thumb
should be under the fan housing.
NOTICE
Do not stand or kneel on the drive tube.
N Hold the starter grip with your right
hand.
N Pull the starter grip slowly until you
feel it engage and then give it a brisk
strong pull.
NOTICE
Do not pull out the starter rope all the
way – it might otherwise break.
N Do not let the starter grip snap back.
Guide it slowly back into the housing
so that the starter rope can rewind
properly.
N Continue cranking until the engine
runs.
As soon as the engine runs
N Press down the throttle trigger
lockout and open the throttle – the
choke knob moves to the run
position F. After a cold start, warm
up the engine by opening the
throttle several times.
g if the engine is cold
< for warm start – also use this posi-
tion if the engine has been running
but is still cold.
0000-GXX-0478-A0
0000-GXX-1674-A0
0000-GXX-1319-A0
0000-GXX-1318-A0
0000-GXX-1558-A0

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Stihl KM 131 R and is the answer not in the manual?

Stihl KM 131 R Specifications

General IconGeneral
Engine Type4-MIX
Displacement36.3 cc
Sound Pressure Level98 dB(A)
Sound Power Level110 dB(A)
Warranty2 years
Power Output1.4 kW
Engine Power1.9 bhp
Weight4.4 kg
Weight (without cutting attachment)4.4 kg
Fuel Capacity710 cc (24.0 oz)
Vibration Level Left/Right4.9 / 4.9 m/s²
Vibration Levels (left/right)4.9 / 4.9 m/s²
