Stihl KM 131 R User Manual

KM 111 R, KM 131 R
English
23
1 Fuel Filler Cap
2 Carburetor Adjusting Screws
3 Starter Grip
4 Manual Fuel Pump
5 Cover
6 Muffler with Spark Arresting Screen
7 Machine Support
8 Coupling Sleeve
9 Wing Screw
10 Loop Handle
11 Barrier Bar
12 Carrying Ring
13 Stop Switch
14 Throttle Trigger Lockout
15 Throttle Trigger
16 Choke Knob
17 Air Filter Cover
18 Fuel Tank
# Serial Number
Main Parts
16
15
14
13
12
10
11
9
8
5
4
3
2
1
0000-GXX-0497-A0
#
6
7
17
818

Stihl KM 131 R Specifications

General

Engine Type	4-MIX
Displacement	36.3 cc
Sound Pressure Level	98 dB(A)
Sound Power Level	110 dB(A)
Warranty	2 years
Power Output	1.4 kW
Engine Power	1.9 bhp
Weight	4.4 kg
Weight (without cutting attachment)	4.4 kg
Fuel Capacity	710 cc (24.0 oz)
Vibration Level Left/Right	4.9 / 4.9 m/s²
Vibration Levels (left/right)	4.9 / 4.9 m/s²
