Stihl MS 170 - Specifications; Become Familiar with the Controls; Master Control Lever

© STIHL Inc., Virginia Beach, VA 2013 US/STR
confidential
Specifications
 Engine Displacement 30.1 cc (1.8 cu.in) 31.8 cc(1.9 cu. in.)
 Engine Power 1.3 kW (1.7bhp) 1.5kW (2.0 bhp)
 Weight 3.9 kg (8.6 lbs) 4.0 kg (8.8 lbs.)
 Fuel Capacity 250 cc (8.5 oz.)
 Chain Oil Capacity 145 cc (4.9 oz.)
 Recommended OILOMATIC® Chain 3/8” PMM3
 Guide Bar Lengths Available 12” to 16”
 Engine Idle Speed 2800 RPM
 Wide Open Throttle 14,000 RPM (with bar and chain installed)
MS 170 MS 180
© STIHL Inc., Virginia Beach, VA 2013 US/STR
confidential
Become Familiar With the Controls
Master Control Lever™
A single lever
operating the choke,
throttle lock and on-off
switch
0 = Off
I = Ignition on
Warm Start
Cold Start
2
