Stihl Ms 201

MS 201, MS 201 C
English
44
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
Engine
Single cylinder two-stroke engine
Ignition system
Electronic magneto ignition
(breakerless)
This ignition system fulfills all
requirements of the Canadian
Interference-Causing Equipment
Regulations ICES-002.
Fuel system
All position diaphragm carburetor with
integral fuel pump
Chain lubrication
Fully automatic, speed-controlled oil
pump, additional manual oil flow control
Weight
Cutting attachment
Rollomatic guide bars
Saw chains 3/8"Picco
Chain sprocket
Additional cutting attachments
Additional cutting attachments
complying with CSA Standard Z 62.3
are available: see section CSA Standard
Z 62.3, "Information Sheet" in saw chain
packaging or ask a STIHL servicing
dealer.
Your STIHL servicing dealer will be
happy to help you properly match your
engine with the appropriate bar/chain
combinations to reduce the risk of
kickback injury.
Specifications
A = 300 hours
B = 125 hours
C = 50 hours
Displacement: 35.2 cm
3
Bore: 40 mm
Stroke: 28 mm
Engine power to
ISO 7293:
1.8 kW (2.4 HP)
at 9500 1/min
Idle speed: 3000 rpm
Maximum permissi-
ble speed with bar
and chain: 14000 rpm
Spark plug
(suppressed): NGK CMR 6 H
Electrode gap: 0.5 mm
Fuel tank capacity: 0.31 l
Oil tank capacity: 0.22 l
dry, without bar and chain
MS 201: 3.9 kg
MS 201 C: 4.0 kg
Cutting length (3/8"
pitch): 12", 14", 16", 18"
Groove width: 1.3 mm
Picco Micro 3 (63 PM3) Type 3636
Pitch: 3/8"P (9,32 mm)
Drive link gauge: 1,3 mm
Picco Super 3 (63 PS3) Type 3616
Pitch: 3/8"P (9,32 mm)
Drive link gauge: 1,3 mm
Picco Duro 3 (63 PD3) Type 3612
Pitch: 3/8"P (9,32 mm)
Drive link gauge: 1,3 mm
6-tooth for 3/8"P (spur chain sprocket)
