MS 201, MS 201 C
English
31
Installing the spark plug
N Install the spark plug and connect
the spark plug boot (press it down
firmly) – reassembly all other parts
in the reverse sequence.
Removing the starter
N Remove screws (1)
N Lift the fan housing off of the
crankcase and pull it away to the
side
Remove the rope rotor
Version with ElastoStart
N Remove the spring clip (1)
N Carefully remove the rope rotor with
washer (2) and pawl (3)
The rewind spring can jump out – risk of
injury!
Version with ErgoStart
N Remove the spring clip (1)
N Carefully remove the carrier with
washer (2) and pawls (3) from the
rope rotor
N Carefully pull off the rope rotor (4)
The rewind spring can jump out – risk of
injury!
Replacing the Starter Rope
and Rewind Spring
