MS 201, MS 201 C
English
32
Replacing a torn starter rope
Version with ElastoStart
N Pry the cap out of the starter grip
N Remove remaining rope from the
rotor and starter grip
N Thread the new starter rope through
the starter handle and secure it by
making a simple overhand knot
N Pull the knot into the starter grip
N Refit the cap in the grip
Version with ErgoStart
N Remove remaining rope from the
rotor and starter grip
N Thread the new starter rope through
the starter grip and secure it by
making a knot
Installing the rope rotor
Version with ElastoStart
N Thread the rope from above through
the rope guide bush (1) and rope
rotor (2) and secure with a simple
overhand knot
N Coat the bearing bore in the rope
rotor with non-resinous oil
N Slip the rope rotor onto the starter
post (3) – turn it back and forth a
little until the anchor loop of the
rewind spring engages
